727266-5001W / 452301-5001W GT2052 Garrett renoverad original turbo OEM : 2674A391,2674A326 ( Bytesturbo )

  • 12 000 kr
  • 7 000 kr

727266-5001W Garrett bytesturbo original turbo som tas in i vårat bytessystem. ( Beställningsvara 2-3 dagars levtid ) Packningssats + pinnbultar + muttrar

I lager.
Lagersaldo: 1
Artikelnummer: 727266-5001WBT
Dela

727266-5001W Garrett bytesturbo original turbo som tas in i vårat bytessystem. ( Beställningsvara 2-3 dagars levtid )

Packningssats + pinnbultar + muttrar ingår !

Part Number727266-5001S
Previous Version452301-0001, 727266-0001
OE number2674A391, 2674A326, 02202400
Year2002-
DescriptionIndustrial JCB 3CX, 4CX
CHRA451298-0045 (451298-0024) (1102020440) : Finns att köpa !
Turbo ModelGT2052, GT2052S
Engine1004-40T
Displacement4000 ccm, 4 Cylinders
Fuel Diesel
Angle α (compressor housing)185º
Angle β (turbine housing)105º
Bearing Housing433275-0002 (435793-0002, 713782-0002) (1102015450)(Oil Cooled)
Turbine Wheel434715-0039 (434715-0007, 434715-0013, 434715-0027) (1102020440) (47.0 mm )
Comp. Wheel436131-0003  (436131-0021, 451584-0010, 705878-0017)(Ind. 36.75 mm, Exd. 52. mm, Trm  50, 6 Blades, Extended back disc type)
Back plate721085-0001  (434689-0002)(1102015316/1102015314)
Heat shield Number434302-0001 (434684-0001) (1102015343)
Repair Kit732252-0001 (1102015756)
Thrust Kit732248-0003
Turbine Housing436383-0002
Compressor Cover436414-0010
Turbine Housing AR0.50
Actuator434133-0022/434133-0047
Gasket (turbine inlet)210658 (Inox Steel)
Gasket (oil outlet)210243 (Paper)
ManufacturerHoneywell-Garrett


Applications


2002-  Perkins Industrial Engine 1004-40T


Bytesturbo = gamla turbon skall i retur till oss här!

Fabriksny utan stomme i retur finns relaterad under. ( 1500 kr inkl moms extra )
