465776-5011S Garrett TA3106 fabriksny originalturbo

  • 11 999 kr
  • 10 199 kr

465776-5011S Garrett TA3106 fabriksny originalturbo.Komplett monteringssats inklusive packningar,pinnbultar,muttrar ingår vid köp utav denna turbo online.Vi ren

I lager.
Artikelnummer: 465776-5011S
Dela

465776-5011S Garrett TA3106 fabriksny originalturbo.

Komplett monteringssats inklusive packningar,pinnbultar,muttrar ingår vid köp utav denna turbo online.


Vi renoverar även denna turbo väldigt ofta här,Maila / Ring för prisuppgift samt levtid.

Garrett turbonummer / Ersättningsnummer  : 465776-5011S
465776-5011W, 465776-5011, 465776-0011, 465776-11

Originalnummer Volvo : 9004881547, 11033558, 9011033558, 11033708, 9011033708

Turbonummer / originalnummer / Turbofakta :

Part Number465776-5011S
Previous Version465776-0011, 465776-0010, 465776-10, 465776-11
OE number9004881547, 11033558, 9011033558, 11033708, 9011033708
DescriptionIndustrial Nissan; Volvo F.End Loader, L7OB Loader L70C
CHRA409172-0086 (409172-5086S)(87840385) $450.00 NEW IN STOCK, MADE IN USA
Turbo Model TA3106
Engine ManufacturerNavistar
EngineTD61/63,  TD63 EN-91
Engine Configuration  5400/6700 ccm, 6 Cylinders
FuelDiesel
Angle α (compressor housing)228º
Angle β (turbine housing)345º
Bearing Housing430027-0022 (312379, 407285-0027, 407285-0038, 430027-0025, 430027-0048)(Oil Cooled)(1100030450,  1900011104B)
Turbine Wheel445812-0001 (E0NN6N678AA)(Ind. 54.5 mm, Exd. 61. mm, Trm 79, 10 Blades)
Comp. Wheel446340-0003 (E0NN6N662AA)(Ind. 40.56 mm, Exd. 60.1 mm, Trm 8.9, 6+6 Blades)(1200-016-561)
Back plate409629-0021
Heat shield Number409627-0000 (103121-0000, 409627-0001)(1100030340)
Repair Kit468139-0000 (EFPN6K682AA)(1100030750, 5000010041)(Dynamic)
Turbine Housing441293-0046
Compressor Cover409115-0110 (87840384)
Turbine Housing AR0.82
Gasket (turbine inlet)409039-0000 (2405022) (Stainless Steel)
Gasket (turbine inlet)409039-0000 (210022-0000) $13.52
Gasket  oil inlet210023  (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762,  409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)
Gasket (oil outlet)210021 (148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027) $3.32
Gasket Kit215119 (2090505058)
ManufacturerHoneywell-Garrett


Applications


Nissan Industrial Engine TD63 EN-91

L70C

Volvo Earth Moving L70B Loader, F.END Loader TD61 EN-91

Volvo Trucks L70   Engine TD63 EN-91
