53269886501 K26 Renovering av din turbo - BF6M2013EC

  • 7 499 kr
  • 6 749 kr

53269886501 K26 Renovering av din turbo - BF6M2013EC- Renovering utav din befintliga turbo till perfektion.- 3 års garanti.- Renoveras utav erfarna turboteknike

I lager.
Article Number: 53269886501-R
Share

53269886501 K26 Renovering av din turbo - BF6M2013EC

- Renovering utav din befintliga turbo till perfektion.

- 3 års garanti.

- Renoveras utav erfarna turbotekniker där en diagnos även gör vad som kan ha orsakat haveriet.

Turbonummer / Originalnummer / Turbofakta :

Part Number 53269886501
Previous Version5326-988-6501 5326 988 6501
OE number04259722, 03047687, 4259722, 3047687, 04259722KZ, 03047687KZ, F71820209001, F718202090010,  04252301, 12152917
Year 2001-
DescriptionDeutz (M.W.M.)  Tractor, Fendt Various 711 712 714 716 716 815 817 818 TMS
Manufacturer Part Number53269706501, 5326-970-6501, 5326 970 6501
CHRA53267100084 (5326-710-0084) $850.00
Turbo ModelK26-3065OXAKB10.22GASQB
EngineBF6M2013EC, TD226-B3
Displacement 5.7L, 5700 ccm
KW148/201
RPM Max2100
FuelDiesel
Angle α (compressor housing)260°
Angle β (turbine housing) 10°
Bearing Housing53261500026 (53241500004, 53261500016) (858705)  $150.34 NEW IN STOCK
Turbine Wheel53261205011 (53261205009, 53261202128, 53261205002) (Ind. 58.7 mm, Exd. 82. mm, 12 Blades) $355.01
Comp. Wheel53271232336
Back plate53271516810 (53271516737) $54.00 NEW IN STOCK
Heat shield Number53261652005 (53261652007) $22.75 NEW IN STOCK
Repair Kit53267110500 (53277110053, 53277110030) (1301027760) $153.89 NEW IN STOCK
Turbine Housing53261016510 (53261016508)
Compressor Cover53271013109 (53271013220)
Turbine Housing AR10
Gasket Kit215408  27-898101475$57.12
Gasket (oil outlet)210172 (Gasket paper) $2.00
Gasket (oil Inlet)210023 (52231586500, 147837) $4.48
NOTEIntercooler
ManufacturerBorg Warner - 3K - Schwitzer


Applications


2001-  Deutz (M.W.M.) Agricultural Tractor with BF6M2013EC Engine
