856800-5002S Garrett GTX2860R Gen 2 turbo A/R 0,72 V-bandshus

  • 18 000 kr
  • 15 300 kr

856800-5002S Garrett GTX2860R Gen 2 turbo A/R 0,72 V-bandshus ( Beställningavara 3-10 dagar ) Mycket populära GTX2860R GEN 2 med minsta V-bandshuset A

I lager.
Artikelnummer: 856800-5002S
Dela

856800-5002S Garrett GTX2860R Gen 2 turbo A/R 0,72 V-bandshus ( Beställningavara 3-10 dagar )


Mycket populära GTX2860R GEN 2 med minsta V-bandshuset A/R 0,72.

  Information ifrån tillverkaren Garrett motion :

 Horsepower: 200 - 475 HP
Displacement: 1.4 - 2.5 L
V-Band Inlet - V-Band Outlet - Single Scroll - A/R 0.72




  • Gen II Aero forged milled compressor wheel
  • High-Flow Compressor Housing with integrated speed sensor port
  • Rotation: Standard (Clockwise)
  • Dual ceramic ball bearing cartridges
  • Inconel Turbine Wheel
  • Water- and Oil Cooled
  • External Wastegate
  • Replaces: 836040-5002S



  Compressor side:
Inducer ø
46.00mm		Exducer ø
60.00mm		Trim
58		A/R
0.60

  Turbine side:
Inducer ø
54.00mm		Exducer ø
47.00mm		Trim
76		A/R
0.57
