53319887130 Volvo Penta D9 Renovering ( Renovering )

53319887130 Volvo Penta D9 Renovering ( Renovering )

- Renovering utav er befintliga D9 turbo till perfektion utav erfarna turbotekniker.

- Byggs med originaldelar.

- Levtid : 1-2 dagar vid normal belastning i verkstad.

Turbonummer / Originalnummer / Turbofakta :

 Part Number: 53319987130

Turbonummer / ersättningsnummer BorgWarner : 5331-998-7130, 5331 998 7130, 53319707130,  5331-970-7130, 5331 970 7130, 53319887130, 5331-988-7130, 5331 988 7130

Originalnummer Volvo Penta  : 3801114, 3808049, 3838871, 3842676

Turbo Model: K31, K31-3971QYAKB/20.90, K31-3971QYAKB20.90DCAWD

Manufacturer: BorgWarner - 3K - Schwitzer, BWTS DE

Year: 2003-11

Engine: D9 P1025, D9P1025

Engine Manufacturer: Volvo Penta

Displacement: 9.36L, 93600 ccm

Fuel: Diesel

Power: 420 kW/571 HP

Speed: 1860 RPM

Angle α (Compressor Housing): 88/92°

Angle β (Turbine Housing): 60°

Back Plate: 53291523003 (53291523001)(204290001)

Bearing Housing: 53291500024 (53291500008)(Oil Cooled)

CHRA: 53317100020 (5331-710-0020, 5331-710-0040)

Compressor Cover: 53311013116

Compressor Wheel: 53331232015 (53331232014)(Ind. 71 mm, Exd. 102 mm, Trim 6.05, 7+7 Blades, Super Back)

Gasket (Oil Inlet): 948883

Gasket (Oil Outlet): 210060 420643

Gasket (Turbine Inlet): 210648

Gasket (Turbine Outlet): 210239

Gasket Kit: 215200

Heat Shield: 53311652001

Repair Kit: 53317110005 (53317110003, 53317110007)(Major)(1301031755)

Turbine Housing A/R: 20

Turbine Housing: 53311007200

Turbine Wheel: 53311205012 (53311205003, 53311205004)(Ind. 85.97 mm, Exd. 74.77 mm, Trim 11.95, 9 Blades)(1100016178)

Wastegate Settings (Lift Shaft): 1.05 mm

Wastegate Settings (Pressure): 2.55 bar

NOTE: Intercooler, water cooled bearing housing.

Application:

2003-11 Volvo Penta Ship with D9 P1025, D9P1025 Engine
