452068-5001s Garrett TB2569 Bytesturbo 1990-98 Saab 900 16V 2.0L .
Packningssats ingår vid köp utav denna turbo.
En riktig Saab klassiker.
Original nummer ifrån Saab :
8828493 , 9146010 , 9185372 , 9187372 , 9198318 , 93184322 , 30584575
Turbonummer / Originalnummer / Turbofakta :
Artikelnummer : | 452068-5001S,452068-5002s,452068-5003s |
Tidigare versioner : | 452068-0001, 452068-0002, 452068-0003, 452068-1, 452068-2, 452068-3 |
OE Number | 8828493, 9146010, 9185372 |
Year | 1990-98 |
Description | Saab 900 16V, 2.0L |
CHRA | 443854-0093 |
Turbo Model | TB2569 |
Engine Model | B204E,B204L,B204R |
Bränsle | Bensin |
KW | 154/185/200 HP |
Displacement | 2.0L, 1985 ccm, 16V Cylinders |
Angle α (compressor housing) | 79° |
Angle β (turbine housing) | 142° |
Bearing Housing | 444360-0012 |
Turbine Wheel | 435922-0001 |
Comp. Wheel | 446335-0010 |
Heat shield Number | 443594-0001 |
Repair Kit | 709143-0001 |
Turbine Housing | 413567-0034 |
Compressor Cover | 409589-0342 |
Turbine Housing AR | 0.49 |
Tillverkare | Turboshop Sweden AB |
Condition | Rebuilt |
Bytesturbo = Gamla turbon skall i retur.
