465600-5009S Renovering utav originalturbo Garrett T04B46 Motorkod : TD60B ( Renovering )

  • 604.42 EUR
  • 543.98 EUR

465600-5009S Renovering utav  originalturbo Garrett T04B46 Motorkod : TD60B ( Renovering )FIXA BILD- Renovering utav din originalturbo- 3 års garanti.- Kom

I lager.
Varenummer: 465600-5009S-R
Del

465600-5009S Renovering utav  originalturbo Garrett T04B46 Motorkod : TD60B ( Renovering )


FIXA BILD

- Renovering utav din originalturbo

- 3 års garanti.

- Komplett monteringssats.

Turbonummer / Originalnummer / Turbofakta :

Part Number 465600-5009S
Previous Version465600-0003, 465600-0002,  465600-0009, 465600-0005, 465600-0006
OE number 846633,  9000846633
Description Truck, Forklift
CHRA408105-0063 (408105-5063S)(310280A, 465361, 3545888) $300.00 NEW IN STOCK, MADE IN USA
Turbo Model T04B46
Engine TD60B
KW 133/178
RPM Max 2800
Displacement 5.48L, 5480 ccm, 6 Cylinders
Bearing Housing430027-0025  (312379, 407285-0027, 407285-0038, 407285-0064, 430027-0022,  430027-0048)(Oil Cooled)(1900011104B) $69.00 NEW IN STOCK
Turbine Wheel451309-0002  (317640, 407276-0005, 410188-0002, 410188-0005, 410188-0014,  446249-0004, 446905-0001)(Ind. 74.29 mm, Exd. 58.29 mm, Trm 9.19, 11  Blades)(1100030024) $105.00 NEW IN STOCK
Comp. Wheel409179-0018 (Ind. 48.38 mm, Exd. 70. mm, Trm 6.96, 8+8 Blades, Flatback)(1200020110) $39.00 NEW IN STOCK
Back plate408045-0051 (311708, 312576, 408045-0034, 408045-0035)(1300016009) $40.00 NEW IN STOCK
Heat shield Number409299-0001 (311607, 409299-0000) $15.70 NEW IN STOCK
Repair Kit468100-0000 (3524796, 168984, 310063, 188006-0000)(1100040760, 5000010041) $69.60 NEW IN STOCK
Turbine Housing408102-0023
Compressor Cover408566-0008
Turbine Housing AR 0,84
Gasket Kit215133 (2090505007)
Gasket (turbine inlet)409039-0000 (409039-0001, 210019, 312617, 2405022, 7C7431)(Stainless Steel) $13.52
Gasket (turbine outlet)409196-0001 (Stainless Steel)
Gasket oil inlet210023  (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762,  409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037) $4.48
Gasket (oil outlet)210021 (5264569, 148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027) $3.32
ManufacturerHoneywell-Garrett

Interchangeable with 313913


Applications


Volvo Truck with TD60B Engine

Volvo,  Volvo-Penta Truck with TD60B Engine
