AS13 Volvo Penta / Perkins truck bytesturbo turbo OEM nummer :135756190,13575-6190, 3801341,4T-511,4T511,F41CAD-S0083B,F41CAD-S0083G

  • 782.03 EUR

AS13 Volvo Penta / Perkins truck bytesturbo turbo OEM nummer :135756190,13575-6190, 3801341,4T-511,4T511,F41CAD-S0083B,F41CAD-S0083GMonteringssats medföljer vid

I lager.
Lagersaldo: 1
Varenummer: AS13BT
Del

AS13 Volvo Penta / Perkins truck bytesturbo turbo OEM nummer :135756190,13575-6190, 3801341,4T-511,4T511,F41CAD-S0083B,F41CAD-S0083G

Monteringssats medföljer vid köp utav denna turbo online.

Sitter även på populära Volvo penta

  • D2-75
  • D2-75A
  • D2-75B
  • D2-75C
  • D2-75F

  • D2-60F

 OEM : 3801341

Bytesturbo = gamla turbon skall i retur till oss.

Turbonummer / Originalnummer / Turbofakta :

Artikelnummer :

 VB420083,AS13
Ersättare

VA420083,  VB420093, VC420083, VD420083
Originalnummer :

135756190, 13575-6190, 3801341,  4T-511, 4T511, F41CAD-S0083B, F41CAD-S0083G, F41CADS0083B, F41CADS0083G
Beskrivning

Agricultural Engines, Industrial, Perkins truck, Volvo Penta Boat (Marine) D2-75
V-SPEC
AS13
CHRA
NZ870564 (F41CAD-S0057C, F41CADS0057C)(1450040900 : Finns att köpa.
Turbo Model
RHF4-46001P10NHBRL342CCZ
Engine Model
 N844L-T
Fuel
Diesel
Engine Manufacturer
 Shibaura
Angle α (compressor housing)
80°
Angle β (turbine housing)
152°
Bearing Housing
(Oil Cooled)(1450040450, 1900011259) $85.00 NEW IN STOCK
Turbine Wheel
(Ind. 46.4 mm, Exd. 35.43 mm, Trm 4.67, 9 Blades)(1450040435
Comp. Wheel
(Ind. 31.14 mm, Exd. 45.97 mm, Trm 4.59, 5+5 Blades, Superback)(1450040402, 1200016519)
Back plate
(1300016149)
Heat shield Number
(1450040341, 2030016050)
Repair Kit
NH449813 (1450040751, 5000080027)
Turbine Housing AR
10
 Actuator
 (2061016851)
Gasket (turbine inlet)
210385 (2445130, 2258533)(Stainless Steel)
Gasket (turbine outlet)
210393 (2445136)
Gasket (oil outlet)
210636 (210019)(2485006)(Paper) $4.40
Tillverkare :

IHI
