3532296 / 4033262 H1E Renoverad Holset turbo Motorkod : TXD73 ( Bytesturbo)
- Renoverad originalturbo.
- 3 års garanti.
- Renoverad i vår egna turboverkstad utav erfaren turbotekniker.
Mycket vanlig bytesturbo på den nordiska marknaden.
Packningar + muttrar osv ingår vid köp utav denna bytesturbo.
Bytesturbo = Gamla turbon skall i retur.
Turbonummer / Originalnummer / Turbofakta :
| Part Number | 3532296 |
| Previous Part Number | 3532297 |
| OE number | 865752, 3802076 |
| Description | Truck TXD83 |
| CHRA | 3545711 (3545731, 3575683, 3575683H)(1000020190) $300.00 NEW IN STOCK, MADE IN USA |
| Turbo Model | H1E, H1E-8264AX/H14JA8 |
| Manufacturer Part Number | 4033262, 4033262H |
| Engine | TXD73 |
| Engine Manufacturer | Volvo |
| Fuel | Diesel |
| Angle α (compressor housing) | 360° |
| Angle β (turbine housing) | 360° |
| Bearing Housing | 3502500 (3520574, 3526562)(Oil Cooled)(1152301450, 1900011017) |
| Turbine Wheel | 3522879 (3519892, 3535359)(Ind. 76. mm, Exd. 64. mm, Trm 10.41, 12 Blades, LH) (1152301436, 1100030008) |
| Comp. Wheel | 3599646 (3525398, 3537154, 3537156)(Ind. 54. mm, Exd. 81.78 mm, Trm 6.04, 8+8 Blades, Superback)(1152301403, 1200016658) |
| Back plate | 3522801 (1300016005) |
| Heat shield Number | 3519302 (1152301340, 2030016031) |
| Repair Kit | 4027309 (3802148)(1152301750, 5000020014) |
| Turbine Housing | 3532295 (3532295H) |
| Compressor Cover | 3527987 (3527987H, 352798700) |
| Gasket (turbine inlet) | 3545652/4027309 (1152301750) |
| Gasket (turbine outlet) | 210226 (Stainless Steel) |
| Gasket oil inlet | 147837 (210023) |
| Gasket (oil outlet) | 210021 (148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027) |
| Manufacturer | HOLSET |
Applications
1992- Volvo Truck with TXD73 Engine
