465296-5005S Garrett TCO301 renoverad original Saab turbo till : Saab 900,99 ( Bytesturbo )
- Renoverad originalturbo.
- 3 års garanti.
Ännu 1 unik Saab turbo 1 riktig klassiker för omgående leverans.
Dessa har även 1 separat wastegate som vi kan renovera vid behov !
Vanligt att dessa skickas in ihop med turbon för renovering :)
Turbonummer / Originalnummer/Turbofakta :
Part Number | 465296-5005S |
Previous Part Number | 465296-0005,465296-0001,465296-5001S,465296-5002S,465296-0002 |
OE Number | 935790, 0209502, 209502, 935791, 836618, 8366197 |
Year | 1978-80 |
Description | Saab 900,99 |
CHRA | 409853-0017 (409853-5017S, 935793, 409853-0012) |
Turbo Model | TC0301 |
Engine | B201, B202, B202T |
Displacement | 2.0L 1985 ccm, 4 Cylinders |
Power | 120/127/145 Kw |
Angle α (compressor housing) | 0ďż˝ |
Angle β (turbine housing) | 300ďż˝ |
Bearing Housing | 430027-0025 (312379, 430027-0012, 430027-0029, 430027-0048)(331640728520, 331640728521, 310366)(1100030451) |
Turbine Wheel | 451311-0001 (409646-0051)(Ind. 59.03 mm, Exd. 45.77 mm, 11 blades) |
Comp. Wheel | 409096-0011 (103017-0000, 409096-0004, 409096-0014)(Ind. 60.0 mm, Exd. 37.70 mm, Trm 40, 6+6 blades)(103217-0000)(1100030403) |
Back plate | 430108-0004 |
Heat shield Number | 409639-0000 (409627-0000)(103121-0000) |
Repair Kit | 707897-0001 (200115-0000, 3545830)(1100030750)(Dynamic) |
Turbine Housing | 431350-0003 |
Compressor Cover | 409115-0034 |
Turbine Housing AR | 0.63 |
Gasket (turbine inlet) | 409039-0000 (409039-0001, 210019, 312617, 2405022, 7C7431)(1900000006) (Inox Steel) |
Gasket oil inlet | 210023 (210023-0000, 147837, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037)(Paper) |
Gasket (oil outlet) | 210021 (148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027) |
Manufacturer | Honeywell-Garrett |
NK WANT ME
Applications
1978-80 Saab 900,99 EMS With B201, B202, B202T Engine
