466032-5002S 1984- Volvo 740, 760, 780 TB0326 Turbo ( Bytesturbo )

  • 603.30 EUR
  • 512.81 EUR

466032-5002S 1984- Volvo 740, 760, 780 TB0326 Turbo ( Bytesturbo Ännu en nybyggd unik Volvo turbo som läggs på vårat suveräna byteslager .Byggs på beställning.

I lager.
Varenummer: 466032-5002S-BT
Del

466032-5002S 1984- Volvo 740, 760, 780 TB0326 Turbo ( Bytesturbo

Ännu en nybyggd unik Volvo turbo som läggs på vårat suveräna byteslager .

Byggs på beställning. ( Levtid 1-4 dagar )


Product Description

Part Number466032-5002S
Previous Version466032-0001, 466032-0002, 466032-0003
OE Number1367019, 5002887, 13264254, 1317424, 1326425, 1326425, 5003528-6, 5002887-7, 5002845-5
Year1984-
DescriptionVolvo  740, 760, 780
CHRA409853-0019   (409853-5051S, 409853-0033, 409853-0041, 409853-5019S, 409853-0039) $325.00 NEW IN STOCK, MADE IN USA
Turbo ModelTB0326
EngineB200ET
Engine Manufacturer Volvo
Displacement 2.3L,  2316 ccm, I4    Cylinders
Power  163/177 HP
RPM Max 5200
Fuel Gasoline
Angle α (compressor housing)327º
Angle β (turbine housing)285º
Bearing Housing430027-0025 (312379, 407285-0027, 407285-0038, 430027-0022, 430027-0048)(Oil Cooled) $69.00 NEW IN STOCK
Turbine Wheel451311-0014 (451311-0003, 451311-0004, 451311-0013)(Ind. 58.9 mm, Exd. 48.69 mm, Trm 10.14, 11 Blades) $113.60 NEW IN STOCK
Comp. Wheel409096-0014 (103217-0000, 442198-0001)(Ind. 42.52 mm, Exd. 60.09 mm, Trm 5, 6+6 Blades, Superback) $55.40 NEW IN STOCK
Back plate409629-0003 (409629-0001, 409629-0006, 409629-0007, 409629-0010, 409629-0016) $22.40 NEW IN STOCK
Heat shield Number409639-0000 $14.80 NEW IN STOCK
Repair Kit707897-0001 (200115-0000, 3545830) $71.00 NEW IN STOCK
Turbine Housing430641-0012
Compressor Cover409589-0035/409115-0095
Turbine Housing AR 0.48
Actuator430099-0030
Gasket (turbine inlet)409039-0001 (210190-0000, 132044, 312617)(Inox Steel) $13.20
Gasket (turbine outlet)210275 (Stainless Steel)
Gasket oil inlet 210023  (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762,  409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037) $4.48
Gasket (oil outlet)210021 (409037-0000, 210021-0000, 311496, 413671-0000, 3519807)(1900000027) $4.32
ManufacturerHoneywell-Garrett


Applications


1987 Volvo 200 GLT (Oil cooled)

1982-84 Volvo 200 (Oil cooled) Upg. Engine  B230ET

1985-87 Volvo 740 2.3L (Oil cooled) Engine  B230ET

1985-87 Volvo 760 2.3L (Oil cooled) Engine  B230ET

1985-87 Volvo 780 2.3L Engine  B230ET
